Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H801GPMD
l Static: 32 W
l Maximum: 46 W
2004 bytes
10G GPON interface board
H802XGBC
l Static: 67 W
l Maximum: 85 W
2004 bytes
H801XGBD
l Static: 26 W
l Maximum: 50 W
2004 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
P2P interface board
H801OPFA
l Static: 20.2 W
l Maximum: 28.5 W
1800 bytes
H802OPGD
l Static: 70 W
l Maximum: 100 W
l For V800R011C00 and earlier versions: 1800
bytes
l For V800R012C00 and later versions: 2004
bytes
H802OPGE
l Static: 53 W
l Maximum: 90 W
2004 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
ATM interface board
H801AIUG
l Static: 24.9 W
l Maximum: 33.4 W
-
Combo board
H80BCAME
l Static: 26 W
l Maximum: 75 W
1800 bytes
H806CAME
l Static: 22 W
l Maximum: 69 W
1800 bytes
H80BCVME
l 17a:
– Static: 32 W
– Maximum: 86 W (the
convergence ration is 25%.)
l 8b:
– Static: 32 W
– Maximum: 88 W (the
convergence ration is 25%.)
l PTM: 2000 bytes
l ATM: 1800 bytes
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
175

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
