Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H806CCPE
l 12a/17a:
– Static: 41 W
– Maximum: 97 W (the
convergence ration is 25%.)
l 8b:
– Static: 41 W
– Maximum: 103 W (the
convergence ration is 25%.)
l PTM: 2000 bytes
l ATM: 1800 bytes
H80DCCPE
l 12a:
– Static: 36 W
– Maximum: 91 W (the
convergence ration is 25%.)
l 17a:
– Static: 36 W
– Maximum: 92 W (the
convergence ration is 25%.)
l 8b:
– Static: 36 W
– Maximum: 98 W (the
convergence ration is 25%.)
l PTM: 2000 bytes
l ATM: 1800 bytes
H80DCSPE
l 12a:
– Static: 36 W
– Maximum: 99 W (the
convergence ration is 25%.)
l 17a:
– Static: 36 W
– Maximum: 100 W (the
convergence ration is 25%.)
l 35b:
– Static: 36 W
– Maximum: 103 W (the
convergence ration is 25%.)
l PTM: 2000 bytes
l ATM: 1800 bytes
Voice board
H801ASRB
l Static: 12 W
l Maximum: 37 W
-
H801ASPB
l Static: 15.5 W
l Maximum: 64 W
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
176

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
