Huawei SmartAX MA5608T Hardware Description

3.6.11 Daughter Board
Table 3-9 Daughter board list
Daughter
Board
Corresponding
SCU Board
Function
H801CK
MC
H801SCUB
H802SCUB
H801SCUF
H801SCUN
H802SCUN
H801SCUL
H801SCUK
l Implements the VoIP logic forwarding function,
which is not supported by H801SCUL.
l Implements clock processing and provides the
stratum-3 clock for the system.
l Implements the 1588v2 clock processing function,
which is not supported by H801SCUL, H801SCUB,
H802SCUB and H801SCUF.
l Supports BFD.
H801CK
MD
H801SCUB
H802SCUB
H801SCUF
H801SCUN
H802SCUN
H801SCUL
H801SCUK
l Implements the VoIP logic forwarding function,
which is not supported by H801SCUL.
l Implements clock processing and provides the
stratum-3 clock for the system.
l Implements the 1588v2 clock processing function,
which is not supported by H801SCUL, H801SCUB,
H802SCUB and H801SCUF.
l Implements the 1588ACR clock processing function,
which is not supported by H801SCUL and
H801SCUF.
l Supports BFD.
H801FLB
A
H801SCUB
H802SCUB
H801SCUF
H801SCUN
H802SCUN
H801SCUK
l Supports the VoIP logic forwarding function.
l Supports BFD.
H801M2X
A
H801SCUN
H802SCUN
H801SCUK
NOTE
H802SCUN and
H801SCUK work
together with only
H801M2XA
version B.
l Implements the VoIP logic forwarding function.
l Implements the MAC address extension function.
l Implements clock processing and provides the
stratum-3 clock for the system.
l Supports BFD.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
238

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
