For details about supported optical module, see 4.4 10GE Optical Module and 4.3 GE
Optical/Electrical Module.
Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Green Blinking The board functions
properly
Red Blinking The board is starting up
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
ACT Active
indicator
Green On In active/standby mode or
load-sharing mode, the
board is active
- Off In active/standby mode,
the board is standby
Green Blinking In load-sharing mode, the
board is standby
LINK Link status
indicator
Green On A connection is set up on
the port
- Off No connection is set up on
the port
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
