Huawei SmartAX MA5608T Hardware Description

Number of GEM Port
supported by each port
3872 3872
Number of T-CONT
supported by each port
2048 2048
Split ratio Supports a maximum of
1:128 split ratio.
NOTE
The actual split ratio is
determined according to the
model of optical modules
and the distance of optical
fibers.
Supports a maximum of
1:256 split ratio.
NOTE
The actual split ratio is
determined according to the
model of optical modules
and the distance of optical
fibers.
Outputs 1588V2 time to the
downstream device
Not support Support
Received signal strength
indicator (RSSI) detection and
controlled optical signal
transmission of the optical
module
Support Support
Temperature query and alarm
in case of a high temperature
Support Support
Board power-off in case of a
high temperature
Support Support
3.16.2 H802XGBC Board Description
H802XGBC is a 4-port 10G GPON OLT interface board. It works with the 10G GPON
optical network unit (ONU) to provide 10G GPON access service.
Functional Specifications
Please refer to "10G GPON Service Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
396

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
