Huawei SmartAX MA5608T Hardware Description

In the table, "Yes" indicates "supported" and "No" indicates "not supported".
Table 3-31 Specifications of Ethernet service access boards
Specification H801ETHA H801ETHB
Number of interfaces 8 8
Optical module SFP GE optical module SFP GE optical module or
electrical module
Ethernet cascading Yes Yes
Ethernet upstream
transmission
No Yes
Within-board self
switching (the board
serving as an upstream
board to support
interworking between
upstream ports)
No Yes
GE remote extended
subrack cascading
No Yes (supported in V800R01200
and later versions)
1588ACR Yes Yes
Intra-board aggregation No Yes
Inter-board aggregation No Yes
User access and
management
No No
3.13.2 H801ETHA Board Description
This topic covers the working principle, front panel, port, daughter board, and specifications
of the H801ETHA board.
Functional Specifications
Please refer to "Ethernet Service Access Boards Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
Working Principle
Figure 3-54 illustrates the working principle of the H801ETHA board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
343

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
