Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H801MPWD
l Static: 2 W
l Maximum transfer efficiency: 93%
(220 V, 100% load, 25°C)
-
H801MPWE
l Static: 1.5 W
l Maximum: 1.5 W
-
SPU board
H801SPUA
l Static: 28 W
l Maximum: 35 W
2004 bytes
H801SPUB
l Static: 21 W
l Maximum: 24 W
2004 bytes
H801SPUC
l Static: 53 W
l Maximum: 90 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801SPUF
l Static: 32 W
l Maximum: 50 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
Ethernet service access board
H801ETHA
l Static: 19.6 W
l Maximum: 27 W
1600 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801ETHB
l Static: 20 W
l Maximum: 21 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
TDM service process board
H801CSPA
l Static: 22 W
l Maximum: 23 W
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
173

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
