Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H801X1CA
l Static: 11.1 W
l Maximum: 11.3 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801X2CA
l Static: 20.2 W
l Maximum: 20.5 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801X2CS
l Static: 17.6 W
l Maximum: 18 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H802X2CS
l Static: 7 W
l Maximum: 9 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801X2CK
l Static: 7 W
l Maximum: 9 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H802P2CA
l Static: 9 W
l Maximum: 10 W
2004 bytes
Universal interface board (GPIO)
H801BIUA
l Static: 5.3 W
l Maximum: 5.3 W
-
H801CITA
l Static: 1.9 W
l Maximum: 4.3 W
-
H801CITD
l Static: 3.64 W
l Maximum: 4.55 W
-
Power interface board (PRT)
H801PRTA
l Static: 1.5 W
l Maximum: 1.5 W
-
H801PRTE
l Static: 1.5 W
l Maximum: 1.5 W
-
H801PRTG
l Static: 0.2 W
l Maximum: 0.2 W
-
Power interface board (MPW)
H801MPWC
l Static: 2.5 W
l Maximum: 2.5 W
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
172

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
