Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board is starting up
Red On The board is faulty
ACT Active/
standby
status
indicator
Green On The ACT indicator has no
significant indication until
it is assigned
LINK Link status
indicator
Green On A connection is set up on
the port
- Off No connection is set up on
the port
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
3.14 TDM Service Processing Board
TDM service processing boards include H801TOPA, H801TOPB and H801CSPA.
3.14.1 H801TOPA Board Description
The H801TOPA is a TDM traffic over PSN board. It uses the daughter board to transmit
services upstream.
Functional Specifications
The H801TOPA board supports the following functions:
l Native TDM function (when the NH1A/O2CE daughter board is configured)
l CESoP function (when the EH1A/CSSA daughter board is configured)
l TDM signal upstream transmission through the 16 channels of E1 port (when the NH1A/
EH1A daughter board is configured)
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
352
