Huawei SmartAX MA5608T Hardware Description

Reach 100.00 m
Standards Compliance of the GE Optical Module
Standard ID Description
IEEE 802.3z 1000BASE-X Gbit/s Ethernet over Fiber-Optic at 1 Gbit/s
SFF-8472 Specification for Diagnostic Monitoring Interface for
Optical Transceivers
Standards Compliance of the GE Electrical Module
Standard ID
Description
IEEE 802.3ab 1000BASE-T Gbit/s Ethernet over twisted pair at 1 Gbit/s
4.4 10GE Optical Module
This topic describes the types, specifications, and relation with boards of 10GE optical
modules.
Table 4-5 shows the relation between 10GE optical modules and boards.
Table 4-5 Relation between 10GE optical modules and boards
Board
Type
Board
Name
One-channel
One-fiber Bi-
directional
10GE Optical
Module (SFP+)
One-channel
One-fiber Bi-
directional 10GE
Optical Module
(XFP)
One-channel
One-fiber Bi-
directional 10GE
Optical Module
One-channel
Two-fiber Bi-
directional 10GE
CWDM Optical
Module (SFP+)
Control
board
SCUH/
SCUV/
MCUD1
√ × √ √
Upstream
interface
board
X1CA/
X2CA
× √ √ ×
X2CS/
X2CK
√ × √ √
SPU board SPUA/
SPUC/
SPUF
√ × √ √
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
854

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
