Huawei SmartAX MA5608T Hardware Description

One-channel two-fiber bi-directional 10GE Optical Module (SFP+)
A 10GE optical module (SFP+) is connected to two LC optical fibers to provide one 10GE
channel.
Type One-channel two-fiber bi-directional optical module
No. 1 2 3 4
Operating
Wavelength
850 nm 1310 nm 1550 nm 1550 nm
Encapsulation Type SFP+ SFP+ SFP+ SFP+
Port Rate 10 Gbit/s 10 Gbit/s 9.95 Gbit/s-11.10
Gbit/s
9.95 Gbit/s-10.31
Gbit/s
Minimum Output
Optical Power
-7.30 dBm -8.20 dBm -4.70 dBm 0 dBm
Maximum Output
Optical Power
-1.00 dBm 0.50 dBm 4.00 dBm 4.00 dBm
Maximum Receiver
Sensitivity
-11.10 dBm -12.60 dBm -14.10 dBm -24.00 dBm
Optical Connector
Type
LC LC LC LC
Optical Fiber Type Multi-mode Single-mode Single-mode Single-mode
Reach 0.30 km 10.00 km 40.00 km 80.00 km
Overload Optical
Power
-1.0 dBm 0.5 dBm 0.5 dBm -7.0 dBm
Extinction Ratio 3.0 dB 3.5 dB 3.5 dB 9.0 dB
One-channel two-fiber bi-directional 10GE Optical Module (XFP)
A 10GE optical module (XFP) is connected to two LC optical fibers to provide one 10GE
channel.
Type
One-channel two-fiber bi-directional optical module
No. 1 2 3 4
Operating
Wavelength
850 nm 1310 nm 1550 nm 1550 nm
Encapsulation Type XFP XFP XFP XFP
Port Rate 10.30 Gbit/s 9.95 Gbit/s-10.71
Gbit/s
9.95 Gbit/s-11.10
Gbit/s
9.95 Gbit/s-11.10
Gbit/s
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
855

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
