6.3 B-Type DC PDU
This topic provides the appearance and specifications of the B-type DC PDU, and describes
the function, power distribution principle, input terminals, output terminals, and control
switch of the PDU.
Appearance
Figure 6-14 and Figure 6-15 show the appearance of the B-type DC PDU.
Figure 6-14 Appearance of the B-type DC PDU (with cover)
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
924

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
