Huawei SmartAX MA5608T Hardware Description

Table 6-11 Main performance specifications of the C3-Type DC PDU
Item Performance Specification
Inpu
t
featu
re
Rated input
voltage
-48 V to -60 V DC
Input voltage -38.4 V to -72 V DC
Mode of input
power
Two channels of DC input power. By default, the two channels of
input power are provided by different power sources. To use the
same power source to provide two channels of input power,
connect a jumper to the terminal of each channel, as shown in
Figure 6-10.
Maximum
input current
Maximum input current of each channel is 80 A.
Input terminal M8 OT terminal
Outp
ut
featu
re
Rated output
voltage
-48 V to -60 V DC
output voltage -38.4 V to -72 V DC
Output
channel
Eight channels of output power, controlled by four air breakers
(Each air breaker controls two channels of output power.)
Fixed current
of the air
breaker
40 A
Output
protection
feature
Over-current protection. You need to restore the circuit manually.
Output
terminal
Bare crimping terminal (12-10AWG).
Envi
ron
ment
Working
temperature
-25 °C to 55 °C
Storage
temperature
-40 °C to 70 °C
Relative
humidity
<= 95%
Standard
atmospheric
pressure
70-106 KPa
Dimensions 2 U x 436 mm x 116.4 mm (Height x Width x Depth)
NOTE
1 U = 44.45 mm
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
923

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
