Huawei SmartAX MA5608T Hardware Description

Specification
Class
Specification Description
Regulated voltage
precision
≤ ±0.6%
Peak noise voltage ≤ 200 mV (0 MHz to 20 MHz)
Structure Dimensions (H x W
x D) without
brackets
86.1 mm x 442 mm x 255 mm
Weight ≤ 10 kg (including three 30 A power supply
modules and one SMU01B monitoring
module)
Protection class IP20
Installation mode Installed in an IEC cabinet or an ETSI cabinet
with brackets
Maintenance mode Front access
Cooling method Air cooling, with the built-in fan in the power
supply module
6.5 EPS75-4815AF Power System
The AC-powered cabinet uses the EPS75-4815AF power system to convert the AC input into
the DC and then distribute the power.
Functions
The EPS75-4815AF power system converts one AC input into six DC outputs to implement
the DC power distribution. It can be connected to one to two sets of batteries and use its
monitoring module to manage batteries.
The EPS75-4815AF power system can also use the external sensor transfer box to collect and
report the status of sensors and standby detected parameters.
NOTE
The rectifier modules of the EPS75-4815AF power system work in the load balancing and mutual hot
backup mode.
Appearance
Figure 6-24 shows the appearance of the EPS75-4815AF power system.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
935

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
