Huawei SmartAX MA5608T Hardware Description

Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the phase
of communication with the
control board during its
startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
3.24 SHDSL Service Board
SHDSL service boards provide SHDSL access services using their broadband ports.
3.24.1 SHDSL Service Board Comparison
In the table, "Yes" indicates "supported" and "No" indicates "not supported".
Table 3-165 Specifications lists of SHDSL service boards
Specific
ations
H803SHDA H802SHLB H80ASHLM H802SHGM
Wetting
current
No Yes Yes Yes
Board
Power-
off
No No Yes Yes
Tempera
ture
Query
and
High-
temperat
ure
Alarm
Yes No Yes Yes
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
744

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
