Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H801TOPA
l H801NHlA daughter board:
– Static: 24.2 W
– Maximum: 25.3 W
l H801EH1A daughter board:
– Static: 24.2 W
– Maximum: 25.3 W
l H801O2CE daughter board:
– Static: 24 W
– Maximum: 24.5 W
l H801CSSA daughter board:
– Static: 25 W
– Maximum: 25 W
-
H801TOPB
l Static: 13 W
l Maximum: 16 W
-
GPON interface board
H801GPBC
l Static: 70.6 W
l Maximum: 78 W
l For V800R011C00 and earlier versions: 2000
bytes
l For V800R012C00 and later versions: 2004
bytes
H802GPBD
l Static: 45 W
l Maximum: 51 W
l For V800R011C00 and earlier versions: 2000
bytes
l For V800R012C00 and later versions: 2004
bytes
H805GPBD
l Static: 43 W
l Maximum: 49 W
l For V800R011C00 and earlier versions: 2000
bytes
l For V800R012C00 and later versions: 2004
bytes
H802GPFD
l Static: 45 W
l Maximum: 73 W
2004 bytes
H805GPFD
l Static: 26 W
l Maximum: 50 W
2004 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H806GPBH
l Static: 32 W
l Maximum: 46 W
2004 bytes
H807GPBH
l Static: 25 W
l Maximum: 38 W
2004 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
174

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
