Huawei SmartAX MA5608T Hardware Description

Power Supply
Table 2-14 Power specifications of the IEC service subrack
Item Specification
Power supply mode DC (dual power for backup)
Rated voltage -48 V / -60 V
Working voltage range -38.4 V to -72 V
Maximum input current 40 A
Power Consumption
Table 2-15 Power consumption of the IEC service subrack (Unit: W)
Typical
Configu
ration
Static
power
consump
tion
Maximu
m power
consump
tion
Typical
power
consum
ption
Board configuration
ADSL2+ 290.84 1155.55 723.195 H802SCUN*2+H801X2CS*2+H801CI
TD+H801PRTE*2+H801FCBH
+H805ADPD*14
VDSL2 472.84 1379.55 926.195 H802SCUN*2+H801X2CS*2+H801CI
TD+H801PRTE*2+H801FCBH
+H80BVDPM(17a)*14
POTS 346.84 665.55 506.195 H802SCUN*2+H801X2CS*2+H801CI
TD+H801PRTE*2+H801FCBH
+H808ASPB*14
P2P 1102.84 1631.55 1367.195 H802SCUN*2+H801X2CS*2+H801CI
TD+H801PRTE*2+H801FCBH
+H802OPGD*14
GPON
(H805GP
BD)
724.84 917.55 821.195 H802SCUN*2+H801X2CS*2+H801CI
TD+H801PRTE*2+H801FCBH
+H805GPBD*14
GPON
(H806GP
BH)
570.84 875.55 723.195 H802SCUN*2+H801X2CS*2+H801CI
TD+H801PRTE*2+H801FCBH
+H806GPBD/H806GPBH*14
GPON
(H802SC
UN
+H803G
PFD)
668.84 1085.55 877.195 H802SCUN*2+H801X2CS*2+H801CI
TD+H801PRTE*2+H801FCBH
+H806GPBD/H802GPFD*14
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
90

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
