Huawei SmartAX MA5608T Hardware Description

Typical
Configu
ration
Static
power
consumptio
n
Maximum
power
consumptio
n
Typical
power
consumptio
n
Board configuration
VDSL2 267.84 702.55 485.195 H801SCUN*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H80BVDPM(17a)*6
POTS 213.84 396.55 305.195 H801SCUN*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H808ASPB*6
P2P 537.84 810.55 674.195 H802SCUN*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H802OPGD*6
GPON
(H805GP
BD)
375.84 504.55 440.195 H802SCUN*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H805GPBD*6
GPON
(H806GP
BH)
309.84 486.55 398.195 H802SCUN*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H806GPBH*6
GPON
(H802SC
UN
+H805G
PFD)
273.84 510.55 392.195 H802SCUN*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H805GPFD*6
GPON
(H801SC
UH
+H805G
PFD)
391.84 678.55 535.195 H801SCUH*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H805GPFD*6
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
117

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
