Huawei SmartAX MA5608T Hardware Description

Table 2-34 Boards in the MA5603T chassis
Slot Type Slot Supported Board Remarks
Control board
(SCU) slot
6,7 Control board Two slots must be configured
with the same control board.
You are advised to configure
2 control boards working in
active/standby mode.
Uplink
interface
board (GIU)
slot
8,9 Uplink interface board Mixed configuration of
upstream interface boards is
supported; however, it is
recommended to use the same
upstream interface board in
the configuration.
Power board
slot
10,11 Power board It is recommended to
configure the same power
board in the two slots.
Universal
interface
board (GPIO)
slot
12
l Universal interface
board
l Vectoring processing
board
-
Service board
slot
0-5
l Service board
– SPU board
– Ethernet service
access board
– TDM service
processing board
– GPON service board
– 10G GPON service
board
– P2P interface board
– ATM interface board
– Combo board
– Voice board
– ADSL2+ service
board
– VDSL2 service board
– SHDSL service
board
l SPL board
– ADSL SPL board
– VDSL SPL board
l Extension board
Mixed configuration of
service boards is supported.
When the SPL board is
configured in the slot, select
the slot next to the
corresponding service board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
119

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
