Huawei SmartAX MA5608T Hardware Description

Item Specification
Weight (empty chassis) 3.55kg
Power Supply
Table 2-43 Power specifications of the MA5608T
Item
Specification
Power supply mode DC (dual power for backup) or AC power + battery
Rated voltage DC power supply: -48 V / -60 V
AC power supply: 110 V / 220 V
Working voltage range DC power supply: -38.4 V to -72 V
AC power supply: 100 V to 240 V
Maximum input current DC power supply: 10 A
AC power supply: 6 A
Power Consumption
Table 2-44 Power consumption of the MA5608T chassis (Unit: W)
Typical
Configu
ration
Static
Power
Consumpti
on
Maximum
Power
Consumptio
n
Typical
Power
Consumptio
n
Board Configuration
ADSL2+ 78.5 225.5 152 H801MCUD*2+H801MPW
C+H831FCBB
+H805ADPD*2
VDSL2 104.5 257.5 181 H801MCUD*2+H801MPW
C+H831FCBB
+H80BVDPM(17a)*2
POTS 86.5 155.5 121 H801MCUD*2+H801MPW
C+H831FCBB
+H808ASPB*2
P2P 194.5 293.5 244 H801MCUD*2+H801MPW
C+H831FCBB
+H802OPGD*2
GPON
(H805GP
BD)
140.5 191.5 166 H801MCUD*2+H801MPW
C+H831FCBB
+H805GPBD*2
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
133

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
