Huawei SmartAX MA5608T Hardware Description

Board Name Software Versions Supported
by This Board
Life Cycle
Status
Substitution Relationship
H801SCUK
l Compatible in
V800R008C01SPC317(SPC10
0)
l Compatible in
V800R010C00SPH116
l Compatible in
V800R011C00SPC102
l V800R012C00 and later
versions
N/A N/A
H801SCUV V800R013C00 and later versions N/A N/A
Control board (MCU)
H801MCUD V800R012C00 and later versions N/A N/A
H801MCUE V800R013C00 and later versions N/A N/A
H801MCUD1 V800R012C00 and later versions N/A N/A
Upstream interface board
H801GICD All the versions N/A N/A
H801GICE All the versions N/A N/A
H801GICF All the versions N/A Replaceable with the H801X2CS
board (supported by V800R011C00
and later versions)
H801GICG All the versions N/A Replaceable with the H801GICF
board (supported by
V800R013C10SPH217/
V800R015C00SPC107 and later
patch versions)
H801GICK All the versions N/A Replaceable with the H802GICK
board
H802GICK
l Compatible in V800R017C10–
V800R018C00(supported by
loading the corresponding
patch file)
l V800R018C10 and later
versions
N/A Replaceable with the H801GICK
board
H801GSCA All the versions N/A N/A
H801X1CA All the versions EOM Replaceable with the H801X2CS
board
H801X2CA All the versions EOM Replaceable with the H801X2CS
board
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
151

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
