Huawei SmartAX MA5608T Hardware Description

Board Name Software Versions Supported
by This Board
Life Cycle
Status
Substitution Relationship
H807ADPD
l Compatible in
V800R008C01SPH321+HP30
32+HP3035(SPC100)
l Compatible in
V800R008C02SPH321+HP30
32+HP3035(SPC300)
l Compatible in
V800R010C00SPH116+HP102
2
l Compatible in
V800R011C00SPH111
l Compatible in
V800R012C00SPC101
l Compatible in
V800R013C00SPC101
l Compatible in
V800R013C10SPC206
l Compatible in
V800R015C00SPC101
l Compatible in
V800R015C10SPC101
l V800R016C00 and later
versions
N/A
Replaceable with the H802ADPD/
H805ADPD board
H802ADQD All the versions EOM Replaceable with the H80BVDQM
board
H802ADKM All the versions EOM Replaceable with the H808ADPM/
H807ADPM board
H80BADPE All the versions EOM Replaceable with the H807ADPE
board
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
160

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
