Huawei SmartAX MA5608T Hardware Description

Board Name Software Versions Supported
by This Board
Life Cycle
Status
Substitution Relationship
H807ADPM
l Compatible in
V800R008C01SPH321+HP30
32+HP3035(SPC100)
l Compatible in
V800R008C02SPH321+HP30
32+HP3035(SPC300)
l Compatible in
V800R010C00SPH116+HP102
2
l Compatible in
V800R011C00SPH111
l Compatible in
V800R012C00SPC101
l Compatible in
V800R013C00SPC101
l Compatible in
V800R013C10SPC206
l Compatible in
V800R015C00SPC101
l Compatible in
V800R015C10SPC101
l V800R016C00 and later
versions
N/A
Replaceable with the H808ADPM/
H802ADKM board
VDSL2 service access board
H805VDSA All the versions EOP Replaceable with the H805VDMF/
H80AVDPD board
H805VDSF All the versions EOP Replaceable with the H805VDMF/
H80AVDPD board
H805VDTF All the versions EOP Replaceable with the H802VDNF/
H80BVDQM board
H805VDRD All the versions EOM N/A
H805VDMF All the versions EOM Replaceable with the H80BVDMF/
H80DSDMM board
H80BVDMF
l Compatible in V800R009C00–
V800R017C00
l V800R017C10 and later
version
N/A Replaceable with the H805VDMF
board
H802VDNF All the versions EOM Replaceable with the H80BVDQM
board
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
162

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
