Huawei SmartAX MA5608T Hardware Description

NOTE
l The power consumption of the board is tested in the following conditions:
l Working voltage: -53.5 V DC.
l Ambient temperature: 25 °C.
l Static power consumption: All ports do not carry any loads. Specifically, users under POTS
ports hang up phones, xDSL ports are deactivated, and optical modules are not installed on
optical ports
l Maximum power consumption: All ports fully carry loads. However, only 25% users under
POTS ports concurrently pick up phones and the feeding current is 20 mA.
l The board power consumption slightly varies with the power module configured for the board and
discreteness of components.
Table 3-4 Power consumption and maximum frame size of boards
Board
Power Consumption Maximum Frame Size
Control board (SCU)
H801SCUB
l Static: 18.8 W
l Maximum: 22 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H802SCUB
l Static: 14 W
l Maximum: 17 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801SCUF
l Static: 22 W
l Maximum: 25 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801SCUH
l Static: 89 W
l Maximum: 111 W (Fully
configured with 10GE service
board)
l Maximum: 134 W (Fully
configured with 20GE service
board)
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801SCUL
l Static: 40.4 W
l Maximum: 42.1 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801SCUN
l Static: 41 W
l Maximum: 62 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H802SCUN
l Static: 30 W
l Maximum: 50 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
H801SCUK
l Static: 30 W
l Maximum: 50 W
2052 bytes. After the jumbo frame function is
enabled, a maximum of 9216 bytes can be
supported.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
170

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
