Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H802ADQD
l Static: 25 W
l Maximum: 82.5 W
1800 bytes
H802ADKM
l Static: 28 W
l Maximum: 81 W
1800 bytes
H80BADPE
l Static: 12.4 W
l Maximum: 56.8 W
1800 bytes
H807ADPE
l Static: 20 W
l Maximum: 41 W
1800 bytes
H808ADPM
l Static: 15 W
l Maximum: 62 W
1800 bytes
H807ADPM
l Static: 22 W
l Maximum: 43 W
1800 bytes
VDSL2 service access board
H805VDSA
l Static: 29.4 W
l Maximum: 76.5 W
l PTM: 1600 bytes
l ATM: 1800 bytes
H805VDSF
l Static: 27.3 W
l Maximum: 57 W
l PTM: 1600 bytes
l ATM: 1800 bytes
H805VDTF
l Static: 25.7 W
l Maximum: 60.7 W
l PTM: 1600 bytes
l ATM: 1800 bytes
H805VDRD
l Static: 20 W
l Maximum: 55 W
l PTM: 1600 bytes
l ATM: 1800 bytes
H805VDMF
l 17a:
– Static: 34 W
– Maximum: 80 W
l 8b:
– Static: 34 W
– Maximum: 87 W
l PTM: 1600 bytes
l ATM: 1800 bytes
H80BVDMF
l 17a:
– Static: 18 W
– Maximum: 57 W
l 8b:
– Static: 18 W
– Maximum: 62 W
l PTM:1800 bytes
l ATM:1800 bytes
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
178

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
