Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H80BVCMM
l 17a:
– Static: 30 W
– Maximum: 75 W
l 8b:
– Static: 30 W
– Maximum: 77 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80AVCPD
l 17a:
– Static: 24 W
– Maximum: 65 W
l 8b:
– Static: 24 W
– Maximum: 70 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80DVCPD
l 17a:
– Static: 24 W
– Maximum: 64 W
l 8b:
– Static: 24 W
– Maximum: 70 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80AVCPM
l 17a:
– Static: 26 W
– Maximum: 67 W
l 8b:
– Static: 26 W
– Maximum: 72 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H80DVCPM
l 17a:
– Static: 26 W
– Maximum: 66 W
l 8b:
– Static: 26 W
– Maximum: 72 W
l PTM: 2000 bytes
l ATM: 1800 bytes
H806VCPE
l 17a:
– Static: 24 W
– Maximum: 65 W
l 8b:
– Static: 24 W
– Maximum: 70 W
l PTM: 2000 bytes
l ATM: 1800 bytes
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
180

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
