Huawei SmartAX MA5608T Hardware Description

Board Power Consumption Maximum Frame Size
H806VPEF
l Static: 52 W (not configured with
service board)
l Maximum: 75 W (fully configured
with 6 VCPM boards in Vectoring
mode)
l Maximum: 83 W (fully configured
with 6 SDMM boards in
SuperVector mode)
l Maximum: 94 W (fully configured
with 6 SDPM boards in
SuperVector mode)
-
H806VPGA
l Static: 46 W (not configured with
service board)
l Maximum: 106 W (fully configured
with 12 VCMM boards in vectoring
mode)
-
SHDSL service access board
H803SHDA
l Static: 22 W
l Maximum: 26 W
l PTM: 1594 bytes
l ATM: 1800 bytes
H802SHLB
l Static: 16 W
l Maximum: 23 W
l PTM: 1594 bytes
l ATM: 1800 bytes
H80ASHLM
l Static: 16 W
l Maximum: 21 W
l PTM: 1594 bytes
l ATM: 1800 bytes
H802SHGM
l Static: 22 W
l Maximum: 29 W
l PTM mode: 2000 bytes
l ATM-PTM mode:
– PTM: 1594 bytes
– ATM: 1800 bytes
FAN
H801FCBB
l Static: 23 W
l Maximum: 65 W
-
H801FCBC
l Static: 17 W
l Maximum: 52 W
-
H801FCBH
l Static: 21 W
l Maximum: 88 W
-
H801FCBI
(ETSI)
l Static: 13 W
l Maximum: 67 W
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
182

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
