Huawei SmartAX MA5608T Hardware Description

Table 3-5 Boards supported by the MA5600T/MA5603T
Board
Name
Board Mapping
H801SCUB/
H802SCUB
H801SCU
F
H801SCU
L
H801SCUN/
H802SCUN/
H801SCUK
H801SCU
H
H801SCU
V
Upstream interface board
H801GICD Yes Yes No No Yes Yes
H801GICE Yes Yes No No Yes Yes
H801GICF No No Yes Yes Yes No
H801GICG No No Yes Yes Yes No
H801GICK No Yes Yes Yes Yes Yes
H802GICK No No Yes Yes Yes Yes
H801GSCA Yes Yes No No
l MA5600
T: Yes
l MA5603
T: No
No
H801X1CA No Yes Yes Yes Yes No
H801X2CA No No Yes Yes Yes No
H801X2CS No No Yes Yes Yes Yes
H802X2CS No No Yes Yes Yes Yes
H801X2CK No No Yes Yes Yes Yes
H802P2CA Yes No No
l MA5600T: No
l MA5603T:
– OLT mode:
No
– MSAN
mode(copper
-fiber hybrid
access): No
– MSAN
mode(copper
access): Yes
No No
Universal interface board
H801BIUA
l MA5600T
: Yes
l MA5603T
: No
l MA560
0T: Yes
l MA560
3T: No
l MA560
0T: Yes
l MA560
3T: No
l MA5600T: Yes
l MA5603T: No
No No
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
184

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
