Huawei SmartAX MA5608T Hardware Description

Board
Name
Board Mapping
H801SCUB/
H802SCUB
H801SCU
F
H801SCU
L
H801SCUN/
H802SCUN/
H801SCUK
H801SCU
H
H801SCU
V
H806CCPE Yes Yes No Yes Yes
(V800R016
C00 and
later
versions)
No
H80DCCPE Yes Yes No Yes Yes
(V800R016
C00 and
later
versions)
No
H80DCSPE Yes Yes No Yes Yes No
Voice board
H801ASRB Yes Yes No Yes Yes
(V800R016
C00 and
later
versions)
No
H801ASPB Yes Yes No Yes Yes
(V800R016
C00 and
later
versions)
No
H808ASPB Yes Yes No Yes Yes
(V800R016
C00 and
later
versions)
No
H809ASPB Yes No No Yes Yes
(V800R016
C00 and
later
versions)
No
H80BASPB Yes Yes No Yes Yes
(V800R016
C00 and
later
versions)
No
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
187

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
