Huawei SmartAX MA5608T Hardware Description

For details about supported optical module or electrical module, see 4.3 GE Optical/
Electrical Module.
Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Green Blinking The board functions
properly
Red Blinking The board is starting up
Orange Blinking
(supported in
V800R009C00 and
later versions)
A high-temperature alarm
is generated
Red On The board is faulty
ACT Active
indicator
Green On In active/standby mode,
the board is active
- Off In active/standby mode,
the board is standby
LINK Link status
indicator
Green On A connection is set up on
the port
- Off No connection is set up
on the port
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
Daughter Board
The H802SCUB board can be configured with a matching daughter board. Figure 3-8 shows
the position of the daughter board on the H802SCUB board.
For details about the daughter board and functions supports by the H802SCUB board, see
3.6.11 Daughter Board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
209

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
