Huawei SmartAX MA5608T Hardware Description

Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Green Blinking The board functions
properly
Red Blinking The board is starting up
Orange Blinking
(supported in
V800R009C00 and
later versions)
A high-temperature alarm
is generated
Red On The board is faulty
Red/Green Blinking between red
and green
(supported in
V800R012C00 and
later versions)
The data recovery
completes
NOTE
It is used for the scenario in
which this board replaces the
H801SCUL control board
and then both of them are
installed in the same
subrack.
ACT Active
indicator
Green On In active/standby mode,
the board is active
- Off In active/standby mode,
the board is standby
Green Blinking In load-sharing mode, the
board is standby
LINK Link status
indicator
Green On A connection is set up on
the port
- Off No connection is set up on
the port
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
Daughter Board
The H801SCUN board can be configured with a matching daughter board. Figure 3-17 shows
the position of the daughter board on the H801SCUN board.
For details about the daughter board and functions supports by the H801SCUN board, see
3.6.11 Daughter Board..
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
229

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
