Huawei SmartAX MA5608T Hardware Description

Table 3-30 Functions and specifications of SPU service processing boards
Function/
Specificatio
n
H801SPUA H801SPUC H801SPUF
Application
scenario
Used for multi-RSP
access in the Open
Access scenario and
serves as an upstream
interface board at the
point of
interconnection
(POI).
Used for multi-RSP access
in the Open Access
scenario and serves as an
upstream interface board at
the point of interconnection
(POI).
Supports both Layer 2 and Layer 3
forwarding modes. You can run the
router mode command to configure the
Layer 3 forwarding mode of the system.
l When the basic Layer 3 forwarding
mode is used, the H801SPUF board
works in Layer 2 forwarding mode.
The control board is used as a Layer
3 forwarding board. The H801SPUF
board supports 10 GE upstream
transmission, 1588v2, and Y.1731.
l When the enhanced Layer 3
forwarding mode is used, the
H801SPUF board works in Layer 3
forwarding mode. The H801SPUF
board serves as a Layer 3 forwarding
board, and it is used to expand the
specifications of the ARP/ND entries
and routing entries and to enhance
Layer 3 forwarding capability.
Interfaces
and optical
module
l Eight SFP
interfaces (GE)
l Two SFP+
interfaces (10 GE)
Do not support the
electrical module.
l 20 SFP interfaces (GE);
works with the CSFP
optical module to
provide 40 GE
interfaces
l Four SPF+ interfaces
(10 GE)
Eight SFP interfaces (GE) or SFP+
interfaces (10 GE)
The board port rate supports the
preceding three working modes. When
switching a mode, modify
configurations first. Run the interface
eth frameid/slotid command to enter the
ETH mode and then run the board
speed-mode speed-mode command to
set the port rate mode.
l If speed-mode is 0, the working rates
of ports 0–7 are 1 Gbit/s.
l If speed-mode is 1, the working rates
of ports 0–7 are 10 Gbit/s.
l If speed-mode is 2, the working rates
of ports 0–3 are 1 Gbit/s and
working rates of ports 4–7 are 10
Gbit/s.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
324

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
