NOTICE
l When cables from the LINE ports are routed to an outdoor environment or the user side,
the MDF must be installed with a protective unit.
Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the phase
of communication with the
control board during its
startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking (on for 1 s
and off for 1 s
repeatedly)
A high-temperature alarm
is generated
Red On The board is faulty
BSY Service
online
status
indicator
Green On At least one subscriber port
is activated
- Off None of the subscriber
ports are activated
Pin Assignments
Table 3-46 describes the pin assignments of the LINE0 port on the front panel of the
H806CAME board, and Table 3-47 describes the pin assignments of the LINE1 port on the
front panel of the H806CAME board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
435
