Front Panel Port
VDSL2&POTS port
Connected to
the MDF
NOTICE
l When cables from the LINE ports are routed to an outdoor environment or the user side,
the MDF must be installed with a protective unit.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
439
