Front Panel Port
xDSL0
(0~31)
xDSL1
(32~63)
Connected the port to the
MDF or xDSL port of the SPL
Connected the port to the
MDF or xDSL port of the SPL
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
