l In the downstream direction, the forwarding module decapsulates the IP packets that are

transmitted from the backplane bus, performs CAR on the packets, reassembles the

packets into ATM/PTM packets, and transmits the ATM/PTM packets to the interface

module. The interface module then converts the ATM/PTM packets into analog signals,

and transmits the analog signals over the subscriber line.

Front Panel Port

xDSL

(0-15)

Connected to the MDF

SmartAX MA5600T/MA5603T/MA5608T Multi-service

Access Module

Hardware Description

3 Board

Issue 24 (2018-07-30) Huawei Proprietary and Confidential

747
