Types of Optical and Electrical Modules
Mod
ule
Type
Description Appearance Connector
Type
SFP Small form-
factor
pluggable
optical module.
supports the
highest rate 4
Gbit/s and LC
connectors.
Two-fiber bi-directional optical module
One-fiber bi-directional optical module
LC/PC
SC/PC, SC/UPC
Electrical module RJ-45
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
