Overload Optical
Power
0 dBm -3.0 dBm -3.0 dBm -3.0 dBm -3.0 dBm
Extinction Ratio 9.0 dB 9.0 dB 9.0 dB 8.5 dB 9.0 dB
One-channel One-fiber Bi-directional GE Optical Module
A one-channel one-fiber bi-directional GE optical module is connected to one LC optical fiber
(for both transmission and reception) to provide one GE channel.
Type One-channel one-fiber bi-directional optical module
No. 1 2 3 4 5 6
Operating
Wavelength
Tx: 1310
nm
Rx: 1490
nm
Tx: 1490
nm
Rx: 1310
nm
Tx: 1310
nm
Rx: 1490
nm
Tx: 1490
nm
Rx: 1310
nm
Tx: 1570nm
Rx: 1490nm
Tx: 1490nm
Rx: 1570nm
Encapsulation
Type
eSFP eSFP eSFP eSFP eSFP eSFP
Port Rate 1.25 Gbit/s 1.25 Gbit/s 1.25 Gbit/s 1.25 Gbit/s 1.25 Gbit/s 1.25 Gbit/s
Minimum Output
Optical Power
-9.00 dBm -9.00 dBm -2.00 dBm -2.00 dBm -2 dBm -2dBm
Maximum Output
Optical Power
-3.00 dBm -3.00 dBm 3.00 dBm 3.00 dBm 4 dBm 4dBm
Maximum
Receiver
Sensitivity
-19.50 dBm -19.50 dBm -23.00 dBm -23.00 dBm -26 dBm -26dBm
Optical
Connector Type
LC LC LC LC LC LC
Optical Fiber
Type
Single-
mode
Single-mode Single-mode Single-mode Single-mode Single-mode
Reach 10.00 km 10.00 km 40.00 km 40.00 km 80 km 80km
Overload Optical
Power
-3.0 dBm -3.0 dBm -3.0 dBm -3.0 dBm -3 dBm -3dBm
Extinction Ratio 6.0 dB 6.0 dB 9.0 dB 9.0 dB 9 dB 9dB
Two-channel One-fiber Bi-directional GE Optical Module
A two-channel one-fiber bi-directional GE optical module is connected to two LC optical
fibers (each for both transmission and reception) to provide two GE channels.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
851
