Huawei SmartAX MA5608T Hardware Description

Minimum Output
Optical Power
-15.00 dBm -15.00 dBm
Maximum Output
Optical Power
-8.00 dBm -8.00 dBm
Maximum Receiver
Sensitivity
-32.00 dBm -32.00 dBm
Optical Connector
Type
LC LC
Optical Fiber Type Single-mode Single-mode
Reach 15.00 km 15.00 km
Overload Optical
Power
-8.0 dBm -8.0 dBm
Extinction Ratio 8.5 dB 8.5 dB
Two-channel One-fiber Bi-directional FE Optical Module
A two-channel one-fiber bi-directional FE optical module is connected to two LC optical
fibers to provide two FE channels.
Type
Two-channel one-fiber bi-directional optical module
Operating
Wavelength
Tx: 1550 nm
Rx: 1310 nm
Encapsulation
Type
CSFP
Port Rate 125 Mbit/s-155 Mbit/s
Minimum Output
Optical Power
-14.00 dBm
Maximum Output
Optical Power
-8.00 dBm
Maximum
Receiver
Sensitivity
-28.2 dBm
Optical Connector
Type
LC
Optical Fiber Type Single-mode
Reach 10.00 km
Overload Optical
Power
-8.0 dBm
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
859

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
