Huawei SmartAX MA5608T Hardware Description

Power Supply
Table 2-2 Power specifications of the ETSI service subrack
Specification Value
Power supply mode DC (dual power for backup)
Rated voltage -48 V / -60 V
Working voltage range -38.4 V to -72 V
Maximum input current 40 A
Power Consumption
Table 2-3 Power consumption of the ETSI service subrack (Unit: W)
Typical
Configura
tion
Static
power
consum
ption
Maxim
um
power
consum
ption
Typica
l
power
consu
mption
Board configuration
ADSL2+ 306.84 1266.55 786.695 H802SCUN*2+H801X2CS*2+H801CIT
D+H801PRTE*2+H801FCBI
+H805ADPD*16
VDSL2 514.84 1522.55 1018.69
5
H802SCUN*2+H801X2CS*2+H801CIT
D+H801PRTE*2+H801FCBI
+H80BVDPM(17a)*16
P2P 1234.84 1810.55 1522.69
5
H802SCUN*2+H801X2CS*2+H801CIT
D+H801PRTE*2+H801FCBI
+H802OPGD*16
POTS 370.84 706.55 538.695 H802SCUN*2+H801X2CS*2+H801CIT
D+H801PRTE*2+H801FCBI
+H808ASPB*16
GPON
(H805GPB
D)
802.84 994.55 898.695 H802SCUN*2+H801X2CS*2+H801CIT
D+H801PRTE*2+H801FCBI
+H805GPBD*16
GPON
(H806GPB
H)
626.84 946.55 786.695 H802SCUN*2+H801X2CS*2+H801CIT
D+H801PRTE*2+H801FCBI
+H806GPBH*16
GPON
(H802SCU
N
+H805GPF
D)
530.84 1010.55 770.695 H802SCUN*2+H801X2CS*2+H801CIT
D+H801PRTE*2+H801FCBI
+H805GPFD*16
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
72

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
