Huawei SmartAX MA5608T Hardware Description

Cable Connector X1 Connectors X2 and X3 Color Relationship
X1.2 X2.5 Blue
X1.7 X2.1 White Pair
X1.8 X2.2 Orange
X1.4 X2.6 Green -
X1.Shell X2.Shell Shield -
W2 X1.3 X3.3 White Pair
X1.6 X3.6 Blue
X1.5 X3.5 White -
X1.Shell X3.Shell Shield -
Technical Specifications
Specification
Description
Connector X1 type RJ45 connector
Connector X2 type RJ45 connector
Connector X3 type RJ45 female connector
Cable W1 type Symmetrical twisted pair-100 ohms-4 pairs
Cable W2 type Symmetrical twisted pair-100 ohms-2 pairs
Color Black
Core diameter of the inner
conductor
0.48 mm
Wire gauge of the inner conductor 26 AWG
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
5 Cable
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
907

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
