Huawei SmartAX MA5608T Hardware Description

Indicator Color Status Description
Blinking at a
frequency of 0.5 Hz
There is AC input,
and the power
supply module is in
the manual query
state.
Blinking at a
frequency of 4 Hz
Data is being loaded
online.
Off There is no AC
input.
Alarm indicator Yellow Steady on A protection
mechanism is
triggered. After the
fault is rectified, the
power supply
module can be
restored to the
normal state.
Blinking Communication
between the power
supply module and
the site monitoring
module is
interrupted.
Off Normal
Fault indicator Red Steady on An unrecoverable
fault occurs.
Blinking The power supply
module equipped
with the EMU does
not match the actual
power supply
module.
Off Normal
Table 6-18 lists the indicators on the monitoring module.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
931

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
