8018653 1.1 Installing BSC hardware • 2-11
BRACKET
(4 PLACES)
LAG BOLT
3/8-INCH
BOLT
Figure 2-6. Bracket removal
WARNING
The BSC rack weighs more than 750 pounds
(340 kg). Do not attempt to remove it from the
pallet by yourself. Safety requires at least five
installers: four to remove the rack from the pallet
while one installer operates the pallet truck.
Failure to follow this warning could result in
personal injury.
10. As each installer supports a side of the rack, lift a corner of the
rack and shift the rack by pivoting on the opposite corner.
