Hughes Network Systems GMH2000 User Manual

2-20 • Installing BSC hardware 8018653 1.1
2.4
Anchoring multiple BSC
racks
1. Install two 10 X 100 hex-head mounting screws through the
bottom side frames of the first pair of BSC racks, as shown in
figure 2-13.
MOUNTING
HARDWARE
9007016-0013
9004651-0255
CONTACT
ANGLE
9007016-0016
MOUNTING
HARDWARE
9007034-0005
SPACER
9007016-0017
(2 PLACES)
Figure 2-13. Connecting the bottom frames of the BSC racks together
