8018653 1.1 Installing BSC hardware • 2-25

4. Locate the cable labeled TB1-2 (RTN) and install it into the

PDU terminal block slot labeled TB1-2.

HAZARD

RNING

TB6-2

TB6-1

TB5-2

TB5-1

TB4-2

TB4-1

TB3-2

TB3-1

TB2-2

TB2-1

TB1-2

TB1-1

Figure 2-17. PDU terminal block slot locations
