Hughes Network Systems GMH2000 - Trunk Cable J79, E1 RVS Listing by Cable Connector Pin Number

8018653 1.1 Installing BSC hardware • 2-33
Table 2-6. Trunk cable J79, E1 RVS listing by cable connector pin number
Trunk
Number
Module
Slot/Port
Backplane
Signal Name
Backplane
Conn#.Pin#
Wire Color Code
Solid/Stripe
E1-01 13/1 RVS RING 25 J79.01 White/Blue
RVS TIP 25 J79.02 Blue/White
E1-00 13/0 RVS RING 24 J79.03 White/Orange
RVS TIP 24 J79.04 Orange/White
E1-03 12/1 RVS RING 23 J79.05 White/Green
RVS TIP 23 J79.06 Green/White
E1-02 12/0 RVS RING 22 J79.07 White/Brown
RVS TIP 22 J79.08 Brown/White
E1-05 11/1 RVS RING 21 J79.09 White/Gray (Slate)
RVS TIP 21 J79.10 Gray (Slate)/White
E1-04 11/0 RVS RING 20 J79.11 Red/Blue
RVS TIP 20 J79.12 Blue/Red
E1-07 10/1 RVS RING 19 J79.13 Red/Orange
RVS TIP 19 J79.14 Orange/Red
Shield/Drain wire GND J79.15 Bare Wire
E1-06 10/0 RVS RING 18 J79.16 Red/Green
RVS TIP 18 J79.17 Green/Red
E1-09 9/1 RVS RING 17 J79.18 Red/Brown
RVS TIP 17 J79.19 Brown/Red
E1-08 9/0 RVS RING 16 J79.20 Red/Gray (Slate)
RVS TIP 16 J79.21 Gray (Slate)/Red
Future Expansion 8/1 RVS RING 15 J79.22 Black/Blue
/E1-11 RVS TIP 15 J79.23 Blue/Black
Future Expansion 8/0 RVS RING 14 J79.24 Black/Orange
/E1-10 RVS TIP 14 J79.25 Orange/Black
