2-34 • Installing BSC hardware 8018653 1.1
Table 2-6. Trunk cable J80, E1 FWD listing by cable connector pin number (Cont.)
Trunk
Number
Module
Slot/Port
Backplane
Signal Name
Backplane
Conn#.Pin#
Wire Color Code
Solid/Stripe
E1-01 13/1 FWD RING 25 J80.01 White/Blue
FWD TIP 25 J80.02 Blue/White
E1-00 13/0 FWD RING 24 J80.03 White/Orange
FWD TIP 24 J80.04 Orange/White
E1-03 12/1 FWD RING 23 J80.05 White/Green
FWD TIP 23 J80.06 Green/White
E1-02 12/0 FWD RING 22 J80.07 White/Brown
FWD TIP 22 J80.08 Brown/White
E1-05 11/1 FWD RING 21 J80.09 White/Gray (Slate)
FWD TIP 21 J80.10 Gray (Slate)/White
E1-04 11/0 FWD RING 20 J80.11 Red/Blue
FWD TIP 20 J80.12 Blue/Red
E1-07 10/1 FWD RING 19 J80.13 Red/Orange
FWD TIP 19 J80.14 Orange/Red
Shield/Drain wire GND J80.15 Bare Wire
E1-06 10/0 FWD RING 18 J80.16 Red/Green
FWD TIP 18 J80.17 Green/Red
E1-09 9/1 FWD RING 17 J80.18 Red/Brown
FWD TIP 17 J80.19 Brown/Red
E1-08 9/0 FWD RING 16 J80.20 Red/Gray (Slate)
FWD TIP 16 J80.21 Gray (Slate)/Red
Future Expansion 8/1 FWD RING 15 J80.22 Black/Blue
/E1-11 FWD TIP 15 J80.23 Blue/Black
Future Expansion 8/0 FWD RING 14 J80.24 Black/Orange
/E1-10 FWD TIP 14 J80.25 Orange/Black
To Next Page
