2-32 • Installing BSC hardware
8018653 1.1
HIGH ENERGY
SHOCK
DISCONNECT POW
BEFORE REMOVING THI
WA
R
NIN
T1 RVS
CONNECTOR J87
E1/T1 FWD
CONNECTOR J80
E1/T1 RVS
CONNECTOR J79
T1 FWD
CONNECTOR J86
Figure 2-23. E1/T1 trunk cable connectors
