Hughes Network Systems GMH2000 User Manual

2-18 • Installing BSC hardware 8018653 1.1
Note
The front sleeve braces are located on the side of
the BSC rack that has the Hughes Network
Systems and GMH 2000 logos on it).
4. Using a socket wrench with a 1/4-inch socket, remove the lag
bolts attaching the four brackets to the pallet (see figure 2-6).
5. Using a socket wrench with a 3/8-inch socket, remove the bolts
and lock outs attaching the four brackets to the BSC rack (see
figure 2-6).
Note
You may need to use a 3/8-inch open-end or
combination wrench to hold the lock nuts in
place while you remove the bolts.
WARNING
The BSC rack weighs more than 750 pounds
(340 kg). Do not attempt to remove it from the pallet
by yourself. Safety requires at least five installers:
four to remove the rack from the pallet while one
installer operates the pallet truck. Failure to follow
this warning could result in personal injury.
6. As each installer supports a side of the rack, lift a corner of the
rack and shift the rack by pivoting on the opposite corner.
Continue doing this as you walk the rack to the edge of the
pallet.
7. While two installers stabilize the rack, the other two should
rotate one side of the rack off the pallet and onto the pallet truck
(see figure 2-7).
