IAI RCP6S User Manual

3. Operation
Fieldbus Communication
111
RCP6
S
(2) Input and Output Signal Assignment for each Axis
The I/O signals for each axis consists of 8-word for each I/O bit register.
● The control signals and status signals are ON/OFF signals in units of bit.
● For the target position and current position, 2-word (32-bit) binary data is available and values
from -999999 to +999999 (unit: 0.01mm) can be used. Negative numbers are to be dealt with
two’s complement.
Caution: Set the position data in the range of the soft stroke (0 to effective stroke length)
of the actuator.
● Set the positioning width. The positioning width is expressed using 2-word (32 bits) binary
data. The figures from 0 to +999999 (Unit: 0.01mm) can be set in PLC.
● The command speed is expressed using 1-word (16 bits) binary data. The figures from 1 to
+65535 (Unit: 1.0mm/s or 0.1mm/s) can be set in PLC. A change of the unit is to be
conducted on Gateway Parameter Setting Tool.
● The Acceleration/Deceleration is expressed using 1-word (16 bits) binary data. The figures
from 1 to 300 (Unit: 0.01G) can be set in PLC.
● The pressing current limit value is expressed using 1-word (16 bits) binary data. The figures
from 0 to 100% (00
H
to FF
H
) can be set in PLC.
Caution: Have the setting with values available in the range of for speed,
acceleration/deceleration and pressing current
of the actuator. (Refer to the catalog
or instruction manual of the actuator.) Otherwise, it may cause an abnormal
condition of the servo or a malfunction of the actuator such as the alarm codes 0A3
“Position Command Information Data Error”, 0C0 “Excess Actual Speed”, 0C8
“Overcurrent”, 0CA “Overheated” or 0E0 “Overloaded”.
● The command current is expressed using 2-word (32 bits) binary data (Unit: 1mA).
● The current speed is expressed using 1-word (16 bits) binary data (Unit: 1.0mm/s or
0.1mm/s).
The unit is the one set in the command speed. A positive number is output when the
revolution of the driving motor is in CCW, while a negative number when CW. Negative
numbers are output with two’s complement.
For Slider and Rod Types of actuators, a negative number is output when a movement is
made towards the motor side, while a positive number when against the motor side. For
Reversed Motor Type, it is the other way around.
● The alarm code is expressed using 1-word (16 bits) binary data.
Set Value 00
H
7F
H
FF
H
(127 in decimal system) (255 in decimal system)
Pressing Current Limit Value 0% 50% 100%
3.4.5
ME0349-4B
